$192
i cable ECG or IBP. TT253 ‘HLo’ output of the Spacelabs monitor module to balloon pump, AUX ECG or IBP. Also connects to Vigilance II, Hemosphere continuous cardiac output monitor or Philips Healthcare, Siemens ultrasound AUX ECG input, 1/4″ two circuit phone plug input.
| Dimensions | 14 ft |
|---|---|
| Signal Type | |
| Connects from (signal source - HOST output) | |
| Connects to (signal destination - input) | Edwards LifeSciences cardiac output monitor, Getinge-Maquet-Datascope balloon pump, Philips/Siemens ultrasound |
| Compatible with (OEM) | Edwards LifeSciences, Getinge-Maquet-Datascope, Philips Healthcare, Siemens Healthineers |
i cable Nurse Call. RJ12 normally open alarm output of Spacelabs 90385 monitor to a 1/4″ two circuit right angle phone plug. This device alarm cable is compatible with the Maguire Device Alarm Input Multiplier, which expands the headwall jack to allow simultaneous monitoring of up to three devices.
i cable ECG. DB15HD ouput of the Physio-Control LifePak Defibrillator LP20e with code management module to all GE Healthcare monitors and select ultrasound models Vivid 5, 7, E9, E95 and Logiq Series, 11 pin ECG patient input.
i cable ECG. 9 pin Hypertronics output of Physio Control Defibrillator LP12 and LP15 to all GE monitors and select ultrasound models Vivid 5, 7, E9, E95 and Logiq Series, 11 pin patient ECG input.
i cable ECG Adapter. TT253 ‘HLo’ output of the Spacelabs module adapted to mate with CRM pacemaker programmer cable via the 1/4″ two circuit phone jack. Use in tandem with 1/4″ phone plug pacer programmer cables. This adapter also enables connection to other physiologic monitors via 1/4″ phone plug accessory cables.
i cable ECG. 7 pin ‘Sync In/Marker Out’ of Zoll R Series Defibrillator (model #AF14B034866 and higher or older models which were retrofitted with the female ECG output connector) to the Philips monitor or ultrasound, 12 pin ECG input.
i cable ECG. 7 pin ‘Sync In/Marker Out’ of Zoll R Series Defibrillator (model #AF14B034866 and higher or older models which were retrofitted with the female ECG output connector) to all GE monitors and select ultrasound models Vivid 5, 7, E9, E95 and Logiq Series, 11 pin patient ECG input.
i cable ECG. 1/4″ two circuit phone plug output of the Philips monitor to Boston Scientific Zoom Programmer, AAMI 6 pin ECG input. This cable is compatible with MAGUIRE 257 Series Multipliers and MAGUIRE 414 Series Boom Cabling System, each designed to deliver synchronized waveforms and simultaneous signal transfer onto multiple peripheral device displays. Learn how these low cost products simplify patient setup, reduce cable clutter and enhance any physiologic monitoring system. Is also compatible with MAGUIRE Multi-Defib Output Adapter.
i cable ECG Extension. 6 pin AAMI patient cable extended for ECG patient cables. 6 foot length.
i cable ECG. 1/4″ phone plug output of the Philips monitor or balloon pump to specific GE device inputs, all monitors and ultrasound models Vivid 5, 7, E9, E95 and Logiq Series, 11 pin ECG input. Refer to part# ME590184F for connection to other GE Healthcare models. This cable is compatible with MAGUIRE 257 Series Multipliers and MAGUIRE 414 Series Boom Cabling System, each designed to deliver synchronized waveforms and simultaneous signal transfer onto multiple peripheral device displays. Learn how these low cost products simplify patient setup, reduce cable clutter and enhance any physiologic monitoring system.
i cable ECG. 14 pin MDR output of Draeger Siemens SC7000, SC8000, SC9000, Infinity Delta Series Monitors (not including Axiom Sensis) to balloon pump, Vigilance II, Hemosphere continuous cardiac output monitor, or Philips Healthcare and Siemens ultrasound, 1/4″ two circuit phone plug AUX ECG input. NOTE: Connection from M540 monitor requires adapter #MS20662 available from Draeger.
i cable ECG. Witt Series IV monitors with digital front end, BNC output to Zoll M, R, or X Series defibrillator, AAMI 6 pin ECG input.
i cable ECG. 1/8″ (3.5mm) two circuit phone plug output of Zoll Medical PD and M Series, CCT and Welch Allyn defibrillators to balloon pump, Vigilance II, Hemosphere continuous cardiac output monitor or Philips-Siemens ultrasound, 1/4″ (6.35mm) two circuit phone plug AUX ECG input.
i cable ECG. 7 pin mini DIN “Defib Sync” output of GE monitor to balloon pump, Vigilance II, Hemosphere continuous cardiac output monitor, or Philips Healthcare and Siemens ultrasound, 1/4″ two circuit phone plug AUX ECG input.
i cable ECG. 14 pin MDR output of the Draeger -Siemens SC7000, SC8000, SC9000, Infinity Delta Series and M540 monitors (not including Axiom Sensis ) to Zoll R, X or M Series defibrillator, AAMI 6 pin ECG input. NOTE: connection from M540 monitor requires adapter #MS20662 available from Draeger.
i cable ECG & IBP. TT253 ‘HLo’ output of the Spacelabs module to balloon pump, 1/4″ AUX ECG & IBP inputs. Also connects to the Volcano S5 IVUS Imaging System, AUX ECG & IBP inputs.
i cable ECG. 14 pin MDR output of Draeger Siemens SC7000, SC8000, SC9000, Infinity Delta and M540 monitor (not including Axiom Sensis ) to all GE monitors and select ultrasound models: Vivid 5, 7, E9, E95, 11 pin patient ECG input. NOTE: connection from M540 monitor requires adapter #MS20662 available from Draeger.
i cable ECG. 9 pin Hypertronics output of Physio-Control LifePak LP12 and LP15 to the Boston Scientific ZOOM Pacer Programmer input, AAMI 6 pin ECG input.
i cable ECG. 1/4″ two circuit phone plug output of the Philips monitor or other 1/4″ phono plug output to the Biotronik Renamic & ICS 3000 Pacer Programmer ECG input. This cable is compatible with MAGUIRE 257 Series Multipliers and MAGUIRE 414 Series Boom Cabling System, each designed to deliver synchronized waveforms and simultaneous signal transfer onto multiple peripheral device displays. Learn how these low cost products simplify patient setup, reduce cable clutter and enhance any physiologic monitoring system. Is also compatible with MAGUIRE Multi-Defib Output Adapter.
i cable ECG. 6 pin LEMO output of GE monitor to balloon pump, Vigilance II, Hemosphere continuous cardiac output monitor, or Philips Healthcare and Siemens ultrasound, 1/4″ two circuit phone plug AUX ECG input.
i cable ECG. TT253 ‘HLo’ output of Spacelabs Healthcare monitor to Zoll Medical defibrillator or Maquet-Datascope balloon pump, 6 pin AAMI patient ECG input.
i cable ECG. DB9 output of GE Case 8000, T2100 or Max 1 Stress Tester treadmill to all GE monitors and select ultrasound models Vivid 5, 7, E9, E95 and Logiq Series, 11 pin patient ECG input.
i cable ECG. 7 pin output of the LifePak LP12 and LP15 defibrillator to Philips Healthcare monitor and ultrasound, 12 pin patient ECG input.
i cable ECG. 7 pin mini DIN ‘Defib Sync’ output of GE monitor to all GE monitors and select ultrasound models Vivid 5, 7, E9, E95 and Logiq Series, 11 pin ECG patient input.
i cable Extension. 1/4″ two circuit phone plug adapted to 1/4″ two circuit phone jack. For use with AUX ECG or IBP inputs. 6 foot length.
i cable ECG. 9 pin ‘Defib/Sync’ output of GE Carescape One monitor or PDM module to all GE monitors and specific ultrasound models Vivid 5, 7, E9, E95 and Logiq Series, 11 pin patient ECG input.
i cable ECG. 1/4″ phone plug output of the Philips monitor or balloon pump to the LifePak defibrillator LP12, LP15, LP20, LP20e with code management module, 12 pin ECG input. This cable is also compatible with MAGUIRE 257 Series Multipliers and MAGUIRE 414 Series Boom Cabling System, each designed to deliver synchronized waveforms and simultaneous signal transfer onto multiple peripheral device displays. Learn how these low cost products simplify patient setup, reduce cable clutter and enhance any physiologic monitoring system.
i cable ECG. 1/8″ two circuit phone plug output of the Zoll Medical PD and M Series, CCT or Welch Allyn defibrillators to the Getinge-Maquet-Datascope balloon pump or ultrasound, AAMI 6 pin ECG input.
i cable ECG. 7 pin mini DIN “Defib Sync” output of the GE monitor to LifePak defibrillator LP12, LP15, LP20, LP20e with Code Management Module, 12 pin patient ECG input.
i cable ECG. 1/4″ two circuit phone plug output of the Philips monitor to Medtronic 2090/9790 Pacer Programmer input. This cable is compatible with MAGUIRE 257 Series Multipliers and MAGUIRE 414 Series Boom Cabling System, each designed to deliver synchronized waveforms and simultaneous signal transfer onto multiple peripheral device displays. Learn how these low cost products simplify patient setup, reduce cable clutter and enhance any physiologic monitoring system. Is also compatible with MAGUIRE Multi-Defib Output Adapter.
i cable Nurse Call. 14 pin MDR normally open alarm output of Spacelabs 91369, 91370, 90387, Qube and Xpreazzon monitor to a 1/4″ two circuit right angle phone plug. This device alarm cable is compatible with the Maguire Device Alarm Input Multiplier, which expands the headwall jack to allow simultaneous monitoring of up to three devices.
i cable ECG or IBP. 1/4″ phone plug output of the Philips monitor or balloon pump to Philips/Siemens ultrasound or Edwards LifeSciences Vigilance II , HemoSphere monitor, 1/4″ AUX ECG input. Also connects the 1/4″ IBP output jack of the MAGUIRE 257 Series Multiplier or MAGUIRE 414 Series Boom Cabling System to the balloon pump, continuous cardiac output monitor or ultrasound, AUX ECG input. Maguire 257 and 414 Series Interconnect systems are designed to deliver synchronized waveforms and simultaneous audio signal transfer onto multiple device displays. Learn how these low cost products simplify patient setup, reduce cable clutter and enhance any physiologic monitoring system.
i cable ECG. 9 pin ‘Defib/Sync’ output of GE Carescape One monitor or PDM module to Vivid i or Vivid Q ultrasound, 7 pin Redel AUX ECG input.
i cable ECG & IBP Multiplier. HLO (J10) DB15HD output of the Spacelabs monitor adapted to be 1/4″ two circuit phone jacks, 4 ECG and 2 IBP outputs. Allows simultaneous connection to defibrillator, balloon pump, ultrasound, pacer programmer, continuous cardiac output or other connected physiologic monitor. Use this product in combination with MAGUIRE multiplier cables to deliver ECG and IBP signal to desirable peripheral monitors. Learn how these low cost products simplify patient setup, reduce cable clutter and enhance any physiologic monitoring system.
i cable ECG. 9 pin ‘Defib/Sync’ output of the GE Carescape One monitor or PDM module to balloon pump, Vigilance II, Hemosphere continuous cardiac output monitor, or Philips Healthcare and Siemens ultrasound, 1/4″ two circuit phone plug AUX ECG input.
i cable ECG Extension. 11 pin GE patient cable extended for 3 wire, 5 wire or 10 wire ECG cables. 6 foot length.
i cable ECG. TT253 ‘HLo’ output of the Spacelabs module to LifePak defibrillator LP12, LP15, LP20, LP20e with Code Management Module, 12 pin patient ECG input.
i cable ECG. 9 pin ‘Defib/Sync’ output of GE Carescape One monitor or PDM module to Zoll X, R or M Series, AAMI 6 pin patient ECG input.
i cable ECG. 7 pin mini DIN ‘Defib Sync’ output of the GE monitor to Zoll X, R or M Series defibrillator, AAMI 6 pin ECG input.
i cable ECG. 1/4″ phone plug output from the Philips monitor or Maquet-Datascope balloon pump to the Zoll R, X and M series defibrillator ECG input. Also from the Philips monitor to the balloon pump input or ultrasound, AAMI 6 pin ECG input. This cable is compatible with MAGUIRE 257 Series Multipliers and MAGUIRE 414 Series Boom Cabling System, each designed to deliver synchronized analog audio waveforms and simultaneous signal transfer onto multiple peripheral device displays. Learn how these low cost products simplify patient setup, reduce cable clutter and enhance any physiologic monitoring system.
i cable ECG. 6 pin LEMO output of the GE monitor to Zoll X, R or M Series, AAMI 6 pin ECG input.
